9.5 Technical data of monitor
Data C8600 C9100
Dimensions
375 * 305 * 155
Weight 15 kg 15.5 kg
Ambient temperature 5....+40 °C
Storage temperature -10....+60 °C
Air humidity 15...95% not condensing
System of protection IP40
Supply voltage 110, 120, 130, 220, 230, 240V AC
Voltage tolerance ± 10%
Power consumption 305 VA 480 VA
Fuse rating 110-120V AC
220-240V AC
2 fuses 10AT (slow blow)
2 fuses 5AT (slow blow)
Frequency 50-60 Hz
Mains socket 110-130V AC
220-240V AC
2 A max.
1 A max.
min. 100
Für Deckelmontage
For lid dismantling
305
Monitor
ca. 190
Ø 30
155
375
5999.530-01E 14.01.2004 CSWM 4 54
