3 The monitor
The monitor may only be opened by trained personnel. It contains no parts to be
handled by the operator.
The monitor contains live parts. Hazard of contact due to high voltages of the
assemblies.
The monitor contains electrostatic (ESD) sensitive assemblies. Unsafe contact
may destroy these assemblies.
The monitor consists of a solid metal housing. Its front panel contains the controls. The mains switch
is installed on the back panel and is intended to connect the labeller and power. The following figure
is a front view A and a rear view B of the monitor.
Figure 1: Monitor
Legend
1.
Heatsink
4.
Mains switch
2.
Front panel
5.
Sockets
3.
Cover
6.
Back panel
1 2 3 4
5
6
A
B
5999.530-01E 14.01.2004 CSWM 4 7
