Columbus Instruments CLAMS User Manual

67
CLAMS Hardware Manual 1012-0001 v1.01
Do not tamper with load cell food tray holder or anchor assemblies.
Under no circumstances should the bolt and locknut be adjusted. This risks irreparable damage
to the load cell. If load cell and feeder assemblies require adjustment, contact Columbus
Instruments.
4.4 Feeder Assembly
The feeder assembly contains the following components:
 Hopper with screen (two different material types are shown)
 Push plate
 Spring
 Bowl
