• Using Teflon tape or pipe sealant (which may already have been applied at the factory), thread the
female quick-connect fitting into the output of the pressure regulator (compressed air bottle shown).
Use a 9/16” open-end or crescent wrench to fully tighten.
• When a connection is needed, fully insert the male plug into the female fitting. A spring-like resistance
will be felt, and the integrated locking lever should “click” over the beveled edge of the female fitting,
securing the connection together.
• To remove, simply depress the locking lever and pull the plug free.
2 – Computer Setup
2.1 Minimum Computer Requirements
The host computer is expected to be an IBM-PC compatible running a Windows operating system (XP, Vista, 7,
8.1, 10). It must have a minimum of: 128MB of memory, 1GB of free hard drive space and an free Universal
Serial Bus (USB) port.
2.2 CI-Bus Hub/Switch Mini
The CI-Bus Hub is used to create the interface between the host computer and the CLAMS/Oxymax system. It
connects via a USB port which creates a virtual COM port accessible by the Oxymax software. All
