HANDLING THE PACKAGED MACHINE
Gross weight of machine with packaging is: Vega 2019 65 Bt= 000kg; Vega 2019 75 Bt= 000kg; Vega 2019 85 Bt= 000kg; Vega 2019 70 Bto=
000kg; Vega 2019 70 Bts= 000kg.
The overall dimensions of the package are: A=000cm B=000cm C=000cm
ATTENTION: It is recommended that all the packaging components be kept for any future machine transportation.
ATTENTION: Move the packaged product with handling equipment that complies with legal requirements regarding the size and mass of
the packaging.
HOW TO UNPACK THE MACHINE (versions without PM)
The machine is shipped in specic packaging. To remove it, proceed as follows:
1. Place the lower part of the outer packaging in contact with the oor.
N.B.: Use the pictograms printed on the box as reference.
2. Remove the outer package.
CAUTION: It is recommended that you wear the PPE (Personal Protective Equipment) suited to the work to be carried out.
3. Raise the brush head body and press the brush head control pedal (1) (on the rear of the machine) downwards (Fig.2).
4. Raise the squeegee body and turn the squeegee control lever (2) in the direction of the arrow present in (Fig.3); the lever is located on the
back of the machine.
5. The machine is xed to the pallet by means of chocks, which block the wheels and brush head; remove these chocks.
6. Go to the rear right-hand side of the machine and deactivate the electric brake, turn the lever (3) in the direction of the arrow (Fig.4).
7. Use a ramp to bring the machine down from the pallet.
N.B.: do not t the brush and the rear squeegee body before unloading the machine, and avoid any violent jolts to the brush head and
squeegee support.
N.B.: during the operation to move it by pushing, the electric brake should not be engaged. In any case, the device will be equipped with
safety braking; once a set critical speed has been exceeded, the internal braking system will activate automatically.
HOW TO UNPACK THE MACHINE (versions with PM)
The machine is shipped in specic packaging. To remove it, proceed as follows:
1. Place the lower part of the outer packaging in contact with the oor.
N.B.: Use the pictograms printed on the box as reference.
2. Remove the outer package.
CAUTION: It is recommended that you wear the PPE (Personal Protective Equipment) suited to the work to be carried out.
3. Check that the machine is o, otherwise set the main switch (4) to position "0" by turning the key a quarter turn to the left (Fig. 5). Remove the
key from the instrument panel.
4. Go to the rear right-hand side of the machine and activate the electric brake, turn the lever (3) in the direction of the arrow (Fig.6).
5. Grip the handle (5) on the left-hand side of the recovery tank (Fig.7) and turn the tank as far as it will go.
6. Connect the battery hopper connector to the connector on the general system.
WARNING: This process must be carried out by qualied personnel.
7. Grip the handle (5) on the left-hand side of the recovery tank and turn the tank until it reaches the work position.
8. The machine is xed to the pallet by means of chocks, which block the wheels and brush head; remove these chocks.
9. Turn on the machine, move the main switch to position "I" (4), turning the key a quarter turn to the right (Fig.8).
10. Lift the brush head body, press the “BRUSH HEAD COMMAND” button (6) on the control panel (Fig.9).
11. Switch o the machine by moving the main switch (4) to position "0", turning the key a quarter turn to the left (Fig.5). Remove the key from the
instrument panel.
12. Raise the squeegee body and turn the squeegee control lever (7) in the direction of the arrow present in (Fig.10); the lever is located on the
back of the machine.
13. Go to the rear right-hand side of the machine and deactivate the electric brake, turn the lever (3) in the direction of the arrow (Fig.4).
14. Use a ramp to bring the machine down from the pallet.
N.B.: do not t the brush and the rear squeegee body before unloading the machine, and avoid any violent jolts to the brush head and
squeegee support. during the operation to move it by pushing, the electric brake should not be engaged. In any case, the device will
be equipped with safety braking; once a set critical speed has been exceeded, the internal braking system will activate automatically.
