BATTERY MAINTENANCE AND DISPOSAL
For battery maintenance and recharging, respect the instructions provided by the battery manufacturer.
When the batteries reach the end of their service life, they must be disconnected by a COMAC assistance centre technician or by a specialised
and properly trained worker, and must be subsequently removed from the battery compartment using suitable lifting devices.
N.B.: dead batteries are classied as dangerous waste and as such must be delivered to an authorised body for disposal.
RECHARGING THE BATTERIES
The batteries must be charged prior to rst use, and whenever they no longer provide sucient power to perform the desired work.
CAUTION: The control board and the battery charger, if present on board, can be set for gel or lead-acid batteries; contact your nearest
COMAC assistance centre to modify the correct setting of the machine.
CAUTION: to avoid any permanent damage to the batteries, it is essential to avoid their complete discharge; begin recharging them within a
few minutes of noting the "discharged batteries" signal.
CAUTION: Never leave the batteries completely discharged, even if the machine is not being used.
1. Bring the machine to the battery recharging area.
CAUTION: Park the machine in an enclosed place, on a at and level surface; near the machine there must be no objects that could either
damage it, or be damaged through contact with it.
DANGER: the room used to recharge the batteries must be adequately ventilated to prevent the accumulation of gases that leak from
batteries.
2. Perform the procedure for securing the machine ( see the section titled “SECURING THE MACHINE”).
3. Grip the handle (5) on the left-hand side of the recovery tank (Fig.7) and turn the tank as far as it will go.
To recharge the batteries without the built-in battery charger, proceed as follows:
CAUTION: the following operations must be carried out by qualied personnel. An incorrect connection of the connector may cause
problems with machine functioning.
• Disconnect the electric system connector from the battery connector.
• Connect the external battery charger cable to the battery connector.
• Grip the handle (5) on the left-hand side of the recovery tank (Fig.7) and turn the recovery tank until it reaches the battery charging position.
N.B.: the coupling connector of the battery charger is consigned inside the bag containing this instruction booklet, and must be assembled
on the cables of the battery charger as indicated in the instructions.
DANGER: before connecting the batteries to the battery charger, make sure it is suitable for the batteries used.
N.B.: carefully read the use and maintenance instructions of the battery charger that is used for charging.
CAUTION: keep the recovery tank open for the duration of the battery recharging cycle to allow gas fumes to escape.
• Once the recharge cycle has been completed, rotate the recovery tank to the maintenance position
and disconnect the battery charger's cable from the battery connector.
• Connect the electrical system connector to the battery connector.
• Grip the handle (5) on the left-hand side of the recovery tank (Fig.7) and turn the recovery tank until it reaches the work position.
To recharge the batteries with the on-board battery charger proceed as follows:
CAUTION: the following operations must be carried out by qualied personnel. An incorrect connection of the connector may cause
problems with machine functioning.
N.B.: Carefully read the use and maintenance instructions of the battery charger that is used for charging, this document is delivered along
with the machine.
CAUTION: before connecting the batteries to the battery charger, make sure it is suitable for the batteries used.
N.B.: The charger power cable is delivered inside the bag containing this instruction booklet.
• Plug the battery charger cable into the mains socket.
• Connect the battery charger's power cable to the socket on the battery charger itself.
• Grip the handle (5) on the left-hand side of the recovery tank (Fig.7) and turn the recovery tank until it reaches the battery charging position.
15
