To start working, do as follows:
1. Carry out all the checks in the paragraph “STARTING WORK”.
2. Turn on the machine and move the main switch to position "I" by turning the key (1) a quarter turn clockwise (Fig.1).
3. When the display comes on, three screens appear in sequence:
• The rst screen displayed indicates the logo of the manufacturer of the machine.
• The second screen displayed indicates the name of the machine.
• The third screen displayed indicates the characteristics of the machine's programming.
4. For versions without the PM function, lower the brush head body using the brush head body control pedal (2); the pedal is positioned at the
rear of the machine (Fig.2).
5. For versions with the PM function, lower the brush head body, pressing the “BRUSH HEAD COMMAND” button (3) on the control panel
(Fig.3).
N.B.: As soon as the brush head body is removed from the rest position, the control display shows the symbol (4) (Fig.4).
6. Lower the squeegee body using the squeegee control lever (5); the lever is located on the back of the machine (Fig.5).
N.B.: As soon as the squeegee body is removed from the rest position, the control display shows the symbol (6) (Fig.4).
N.B.: When both symbols (4) and (6) appear on the control display, it means that the “SCRUBBING WITH DRYING” function is being
performed (Fig.4).
7. Turn the tap control lever (7) clockwise; the lever is located on the right-hand side of the machine (Fig.6).
N.B.: Remember to fully open the detergent solution ow, turning the lever as far as it will go (7).
N.B.: To adjust the ow of detergent solution, see “ADJUSTING THE DETERGENT SOLUTION (versions without CDS system)” or
“ADJUSTING THE DETERGENT SOLUTION (versions with CDS system)”.
8. Use the dead man's levers (8) on the instrument panel (Fig.7).
N.B.: The machine has two forward speeds. By pushing the dead man's levers beyond the rst CLICK the “SLOW” speed is activated,
continuing to push the levers beyond the second CLICK the “FAST” speed is activated.
9. Set the required forward speed by turning the knob (9) gradually to the right (Fig.8).
N.B.: To adjust the forward speed, see “SPEED ADJUSTMENT”.
10. When you push the dead man's lever (8), the machine will begin to move.
N.B.: the gearmotor will only begin functioning, and the solenoid valve will only begin dispensing detergent solution, when the brush head
body is in its working position.
11. During the rst few meters, check that the detergent solution coming out is appropriate to the work to be carried out; if this is not the case,
adjust it.
The machine will now begin to work with full eciency until the battery is at or until the detergent solution has nished.
During the rst few metres, check that there is sucient solution and that the squeegee is drying correctly.
N.B.: If the dead man's lever is released during the scrubbing with drying operation, the brush motor and the solenoid valve will be
deactivated. The suction motor will continue working until the squeegee control lever is rotated to bring it back to its idle position.
N.B.: if the squeegee body is raised during the scrubbing and drying operation, the suction motor will continue working at maximum speed
for a certain period of time, and then switch o. This ensures that all the liquid in the vacuum tube is eliminated.
N.B.: when lling the solution tank, it is good practice to empty the recovery tank using the special drainage hose.
BATTERY CHARGE LEVEL INDICATOR
The control display is located on the machine control panel; in the upper left area, a numerical value (10) can be seen that identies the
percentage of charge of the batteries (Fig.4). The graphic symbol adjacent to the numerical value is composed of 5 charge levels, each of which
represents about 20% of residual charge. With a residual charge of 20%, the graphic symbol starts to ash. After a few seconds it appears in a
larger size in the middle of the screen (Fig.9); at this point, you must take the machine to the designated recharging area.
N.B.: a few seconds after the battery charge level reaches 20%, the brush motor switches o automatically. With the remaining charge it is
still possible, however, to complete the drying process before recharging
N.B.: a few seconds after the battery charge level reaches 10%, the suction motor switches o automatically. With the remaining charge, it
is still possible, however, to move the appliance to the location designated for its recharging.
20
