TAG INSERTION (CFC VERSIONS)
To activate automatic eet management data logging (valid for machine versions with CFC), after the screen that enables the machine
programming features to be viewed, insert the TAG in the slot (27) on the rear part of the control handlebar (Fig.27).
N.B.: if the owner of the TAG just inserted is enabled to use the machine, the screen Fig. 28 will appear on the control display; if the TAG
owner is not enabled, the screen Fig. 29 screen will appear.
N.B.: if the machine data connection is active, the symbol (28) will appear in the control display Fig.4.
OVERFLOW DEVICE
The machine is NOT equipped with an overow device, because the volume of the recovery tank is greater than the capacity of the solution tank.
In extraordinary cases, there is a mechanical device (oat) under the recovery tank lid that, when the recovery tank is full, shuts o󰀨 the air to the
vacuum motor intake to protect it; the sound of the suction motor will then be deeper. Empty the recovery tank (see “EMPTYING THE RECOVERY
TANK”).
AT THE END OF THE WORK
At the end of the work, and before carrying out any type of maintenance, perform the following operations:
1. Raise the brush head body and for versions without PM, depress the "BRUSH HEAD BODY CONTROL" pedal (1) at the rear of the machine
fully (Fig.1). For versions with PM, lift the brush head body by pressing the “BRUSH HEAD CONTROL” button (2) on the control panel (Fig.2).
N.B.: to lock the brush head in the raised position, depress the pedal (1) fully and then move it towards the right-hand side of the machine
(Fig.1).
2. Raise the squeegee body and turn the squeegee control lever (3) clockwise (Fig.3).
3. Take the appliance to the dedicated dirty water drainage area.
4. Switch o󰀨 the machine and turn the main switch (4) to position “0" by turning the key a quarter turn anti-clockwise (Fig.4). Remove the key
from the instrument panel.
5. Carry out all the procedures listed in the chapter “RECOMMENDED PERIODIC MAINTENANCE” indicated in the column “AT THE END OF
THE WORK”.
6. Once the maintenance operations are complete, take the machine to the designated storage location.
ATTENTION: Park the machine in an enclosed place, on a at surface; near the machine there must be no objects that could either
damage it, or be damaged through contact with it.
7. Secure the machine, see the section titled “SECURING THE MACHINE”.
ATTENTION: if the machine is left unused for more than one whole day, remove the brush from the brush head body, and the squeegee
body from the squeegee support.
