COMAC Vega 2019 - Draining the Recovery Tank; Cleaning the Recovery Tank Filters; Cleaning the Vacuum Tube; Emptying the Solution Tank

DRAINING THE RECOVERY TANK
Proceed as follows to empty the recovery tank:
1. Release the recovery tank drainage tube (11) (on the left-hand side of the machine) from the retainers (Fig.11).
2. Bend the end of the drainage tube, so as to create a choke and prevent the contents from coming out, put the tube on the discharge surface,
unscrew the cap and gradually release the tube.
3. Repeat the operations in reverse order to reassemble all the parts.
EMPTYING THE SOLUTION TANK
Proceed as follows to empty the solution tank:
1. Release the solution tank drainage tube (18) (on the left-hand side of the machine) from the retainers (Fig.19).
2. Remove the cap and empty the tank; with the solution tank empty, rinse the inside of the solution tank with a jet of running water.
3. Repeat the operations in reverse order to reassemble all the parts.
CLEANING THE RECOVERY TANK FILTERS
To clean the recovery tank (without the optional tank cleaning kit), proceed as follows:
1. Make sure the recovery tank is empty. If this is not the case, empty it (read "EMPTYING THE RECOVERY TANK").
2. Remove the recovery tank cover.
3. Remove the oat cover (12), turning it in the direction of the arrow (Fig.12).
4. Remove the vacuum lter (13) and clean it (Fig.13).
N.B.: you are advised to use a jet of air to remove the impurities before cleaning the lter. Position the lter at least 20cm from the air jet.
ATTENTION: do not use highly corrosive products to clean the lter, to avoid damaging it.
N.B.: If the vacuum lter is excessively worn or damaged, contact the nearest service centre to replace it.
5. Remove the upper part of the oat (14), turning it in the direction of the arrow (Fig.14).
N.B.: when removing the upper part of the oat, be very careful not to remove the lower part as well.
6. Remove the oat (15) (Fig.15). Rinse the inside with a jet of water. If necessary, use a spatula to remove the sludge that has accumulated at
the bottom of the oat.
N.B.: If the polyurethane ring on the oat body (Fig.15) is excessively worn or damaged, contact the nearest service centre to replace it.
7. Remove the dirty water basket/lter from the support (Fig.16).
8. Remove the cover (16) from the basket-lter (17) (Fig.17) and clean under a jet of running water.
N.B.: Use a spatula or brush to eliminate any dirt that is particularly di󰀩cult to remove.
9. Repeat the operations in reverse order to reassemble all the parts.
CLEANING THE VACUUM TUBE
Careful cleaning of the vacuum hose guarantees better cleaning of the oor as well as a longer vacuum motor life. Proceed as follows to clean the
vacuum hose:
1. Stand at the back of the machine.
2. Remove the vacuum hose (1) from the vacuum nozzle (2) on the squeegee body (Fig.1).
3. Remove the vacuum tube (1) via the hole on the back of the recovery tank (Fig.18).
4. Rinse the inside of the vacuum hose with a jet of running water.
5. Repeat the operations in reverse order to reassemble all the parts.
CLEANING THE WATER SYSTEM FILTER
In order to clean the water system's lter, do the following:
1. Block the tap outow, rotating the knob (19) in the direction of the arrow (Fig.20).
2. Go to the right-hand side of the machine and loosen the detergent solution lter cap (20) (Fig.21).
3. Remove the lter cartridge and rinse under a jet of water, using a brush to eliminate any impurities if necessary.
4. Once the lter cartridge is clean, repeat the operations in the opposite order to reassemble all the parts.
