N.B.: Forward speed can be increased by turning the potentiometer's knob (9) clockwise.
N.B.: The appliance has two forward speeds. By pushing the dead man's levers (8) (Fig. 7) beyond the rst CLICK, the “SLOW” speed is
activated; by continuing to push the levers beyond the second CLICK, the “FAST” speed is activated.
N.B.: Adjusting a speed, slow or fast, will imply the automatic modication of the other.
REVERSE ACTIVATION - DEACTIVATION
To reverse, proceed as follows:
1. Check that the squeegee body is raised o󰀨 the oor; if this is not the case, adjust the lever (5) on the back of the device (Fig.12).
2. Press the “REVERSE MOVEMENT ACTIVATION - DEACTIVATION” button (15) on the control panel (Fig.3).
N.B.: As soon as the button (15) is pressed, the “BACK” screen will appear on the control display (Fig.13).
3. Engage the dead man's levers (8) on the handlebar (Fig.7) to start moving the appliance in reverse mode.
N.B.: The reverse speed is lower than the forward speed to comply with current health and safety standards.
N.B.: It is impossible to reverse if the squeegee body touches the oor. In order to reverse, lift the squeegee body from the oor using the
relevant lever on the back of the appliance.
N.B.: To disable reverse movement, press the button (15) on the control panel again.
N.B.: As soon as the button(15) is pressed, the acoustic signal advising that reverse function has been activated will sound.
VACUUM WAND KIT
On request, the machine can be equipped with the liquid vacuum wand kit; in order to use this, proceed as follows:
1. Insert the key (1) into the main switch on the control panel. Set the main switch to "I" (Fig.1).
2. Raise the brush head body and for versions without PM, depress the "BRUSH HEAD BODY CONTROL" pedal (2) at the rear of the machine
fully (Fig.14). For versions with PM, lift the brush head body by pressing the “BRUSH HEAD CONTROL” button (3) on the control panel
(Fig.3).
N.B.: to lock the brush head in the raised position, depress the pedal (2) fully and then move it towards the right-hand side of the machine
(Fig.14).
3. Set the main switch to position "0" by turning the key (1) a quarter turn anti-clockwise. Remove the key from the instrument panel.
4. Lower the squeegee body and turn the squeegee control lever (5) in the direction of the arrow (Fig.5). The lever is located on the back of the
machine.
5. Remove all the vacuum kit components from the storage compartment (Fig.15).
6. Connect the wand kit vacuum tube (17) to the extension tube (16) (Fig.16).
7. Remove the squeegee vacuum tube (18) from the sleeve (19) in the squeegee body (Fig.17).
8. Connect the wand kit vacuum tube (17) to the squeegee vacuum tube (18) (Fig.18).
9. Turn on the machine and turn the key (1) a quarter turn clockwise (Fig.1).
10. Activate the vacuum control kit by pressing the button (20) (Fig.3).
N.B.: As soon as the button (20) on the control display is pressed, the symbol for the vacuum wand kit will appear (Fig.19).
N.B.: With the vacuum wand kit active, the traction and work functions are deactivated.
WARNING: never pick up solid matter such as dust, cigarette stubs, paper, etc.
CAUTION: Never collect gases, explosive/inammable liquids or powders, nor acids and solvents! These include gasoline, paint thinners
and fuel oil (which, when mixed with the vacuum air, can form explosive vapours or mixtures), and also non-diluted acids and
solvents, acetones, aluminium and magnesium powders. These substances may also corrode the materials used to construct the machine.
CAUTION: If the machine is used in dangerous areas (e.g. petrol stations), the relative safety standards must be observed. It is forbidden to
use the machine in environments with a potentially explosive atmosphere.
11. Once the work is complete, disassemble the wand kit and place it in the side support on the machine.
