ID-FLX Lite Global Guide
17
4 Installation and wiring
4.1 Mounting 17
4.2 Package contents 18
4.3 Terminal diagram and dimension 19
4.4 Extension plug-in modules 20
4.5 Communication modules 25
4.6 Remote modules 28
4.7 How to install 32
6 back to Table of contents
4.1 Mounting
The controller is used to be mounted onto the switchboard door. Requested cutout size is 17×112 mm. Use the
screw holders delivered with the controller to fix the controller into the door as described on pictures below.
