5.13.6 IL-NT-BIO8 Binary inputs screen
IN: BIO8 BI1 Alarm
IN: BIO8 BI2 Alarm
IN: BIO8 BI3 Alarm
IN: BIO8 BI4 Alarm
IN: BIO8 BI5 Alarm
IN: BIO8 BI6 Alarm
IN: BIO8 BI7 Alarm
IN: BIO8 BI8 Alarm this line is displayed on the following screen
Note: These screens are shown/hidden depending on whether the IL-NT BIO8 is configured or not.
5.13.7 IL-NT-IO1 Binary inputs screen
IN: BIO8 BI1 Alarm
IN: BIO8 BI2 Alarm
IN: BIO8 BI3 Alarm
IN: BIO8 BI4 Alarm
Note: This screen is shown/hidden depending on whether the IL-NT-IO1 is configured or not.
Analog outputs are not displayed on any screen!
5.13.8 ECU State
ECU State
ECU YellowLamp
ECU RedLamp
WaitToStart
SpeedReq Abs Required RPM of the engine
SpeedReq Rel %
Note: This screen is shown/hidden depending on whether the ECU is configured or not.
