ComAp InteliDrive FLX LITE - General Comparator

ID-FLX Lite Global Guide
68
reduced by Analog output or switched between two levels by Binary output to keep the Engine load on or below
the limit.
Input
Binary input
Binary input
L Request 2
Reg Disable
(optional)
Output Analog output
Load LimitAnOut
Note: LoadLimitAnOut range = 0 - 10000
(plug-in module)
Setpoints Load limit
Load Input = Load
Load Bias
Load Request
Load Request 2
Load ReqRamp
Load UpLimit
Load DownLimit
Load Gain
Load Integral
General comparator
Purpose: Switch on/off some device depends on analog value - e.g. temperature.
Description: The function activates/deactivates some device based e.g. on temperature.
