ID-FLX Lite Global Guide
37
Note: When Engine Control Unit is connected, it is possible to read InteliDrive Analog inputs values AIN1, 2, 3
from CAN bus (J1939).
Note: Precision is 4% ±5Ω.
Note: The nominal range of Analog inputs measuring is 0-10V (0-40V), nevertheless the input is able to
measure up to 12.5V (53V), but with lower precision. Precision is 1%, ±100mV (±400mV).
