InteliLite Global Guide
106
2 Calibration (page 289), or Analog Input 3 Calibration (page 289), or Analog Input 4 Calibration (page 290) directly
to the calculated value at analog input.
Note: The calibration must be done at the operational point of the analog input (e.g. 80°C, 4.0Bar etc..)
Default sensor curves
There are 16 default resistive curves available. The following table provides information on minimum/maximum
values of respective sensors. Actual values especially of temperature curves may differ. Meaning is to prolong
curve to the lower temperature values, so the cold engine will not raise alarm fail sensor.
Curve Min [Ohm] Max [Ohm] Units
VDO 10 Bar 0-2400ohm 0 2400 Bar
VDO40-120°C0-2400ohm 0 2400 °C
VDOLevel%0-2400ohm 0 2400 %
General line 1 0 1000 ohm
General line 2 0 1000 ohm
General line 3 0 1000 ohm
General line 4 0 1000 ohm
General line 5 0 1000 ohm
General line 6 0 1000 ohm
General line 7 0 1000 ohm
General line 8 0 1000 ohm
General line 9 0 1000 ohm
General line 10 0 1000 ohm
General line 11 0 1000 ohm
General line 12 0 1000 ohm
General line 13 0 1000 ohm
Note: Curves can be modified via LiteEdit2015. In LiteEdit2015 are also prepared some standard curves.
IMPORTANT: For right behavior of FUEL LEVEL (PAGE 544) function, curve for this analog input has
to be in percentage and setpoint Fuel Tank Volume (page 185) has to be adjusted correctly.
