InteliLite Global Guide
512
Image 8.187 Stop Solenoid 2
Note: If Additional running engine indications (page 103) are lost during 5s pause than Stop
Solenoid is not activated again otherwise stop solenoid is activated again.
6 Logical binary outputs alphabetically (page 463)
Related FW 1.2.1 Related applications AMF, MRS
Comm object 1249
Description
The binary output depends on measured generator active power. Power is compared with generator nominal
active power with use of hysteresis and with delay of switch 1 s.
When the measured active power is equal or bigger than 5 % of Nominal Power (page 156) for 1 s than the
binary output is closed.
When the measured active power is equal or lower than 3 % of Nominal Power (page 156) for 1 s than the
binary output is opened.
Supplying Load
6 back to Logical binary outputs alphabetically
