InteliLite Global Guide
613
The firmware update process may be performed via any kind of connection including connection via the same
module in which the firmware is to be updated. The connection is reestablished again automatically when the
update process is finished.
Extension modules
EM-BIO8-EFCP 613
EM-BIO8-EFCP
EM-BIO8-EFCP is optional plug-in card. Through this card controller can accommodate one AC current (CT)
measuring input (1A or 5A input) and up to 8 binary inputs or outputs. In LiteEdit2015 PC configuration tool it is
possible to easily choose if particular I/O will be binary input or output.
Image 9.25 EM-BIO8-EFCP interface
IMPORTANT: Any manipulation with plug-in module shall be done with disconnected power
supply to controller.
IMPORTANT: Earth fault current measurement is supported by controller only in slot A.
