InteliPro Reference Guide
4-22
Default setting: None
V Unb Trp BO [ Trp 1 / Trp 2 / Trp 1+2 / None ]
Selection of trip binary output for voltage asymmetry protection.
Default setting: None
PhaseRotation [ CW / CCW / ANY ]
Direction of correct phase rotation.
CW: clockwise
CCW: counter-clockwise
ANY: The protection is blocked, any phase rotation is possible
Default setting: CW
Ph Rot Trp BO [ Trp 1 / Trp 2 / Trp 1+2 / None ]
Selection of trip binary output for phase rotation protection.
Default setting: None
f<>
f>, f>>, f<, f<< [Hz]
Threshold of 1st and 2nd stage overfrequency and 1st and 2nd stage underfrequency protection
respectively.
Step: 0,01 Hz
Range: 0,00 - 70,00 Hz
0 = OFF, the appropriate stage of frequency protection is disabled
Default setting:
− f> 51,5 Hz
− f>> 52 Hz
− f< 47,5 Hz
− f<< 47 Hz
f> del, f>> del, f< del, f<< del [s]
Delay of the appropriate stage of the frequency protection.
Step: 0,01 s
Range: 0,00 - 600,00 s
Default setting:
− f> Del 90,00 s
− f>> Del 0,50 s
− f< Del 20,00 s
− f<< Del 0,50 s
f Block BI [ Block 1 / Block 2 / Block 1+2 / None ]
Selection of blocking binary input for frequency protections.
Default setting: None
f Trp BO [ Trp 1 / Trp 2 / Trp 1+2 / None ]
Selection of trip binary output for frequency protections.
Default setting: None
