ComAp InteliPro Comprehensive Guide

InteliPro, SW version 1.0, ©ComAp – May 2011
InteliPro Reference Guide
4-21
V <>
V>, V>>, V<, V<< [V]
Threshold of 1st and 2nd stage overvoltage and 1st and 2nd stage undervoltage protection
respectively.
Step: 1 V
Range: 1 - 34000 V
0 = OFF, the appropriate stage of voltage protection is disabled
Default setting:
− V> 253 V
− V>> 265 V
− V< 200 V
− V<< 184 V
V> Del, V>> Del, V< Del, V<< Del [s]
Delay of the appropriate stage of the voltage protection.
Step: 0,01 s
Range: 0,00 - 600,00 s
Default setting:
− V> Del 1,00 s
− V>> Del 0,50 s
− V< Del 2,50 s
− V<< Del 0,50 s
V Block BI [ Block 1 / Block 2 / Block 1+2 / None ]
Selection of blocking binary input for voltage protections.
Default setting: None
V Trp BO [ Trp 1 / Trp 2 / Trp 1+2 / None ]
Selection of trip binary output for voltage protections.
Default setting: None
V Unb
V Unb [ % ]
Threshold of the voltage unbalance (amplitude asymmetry). The value corresponds to the maximum
difference between highest and lowest RMS phase voltage of the 3-phase system.
Step: 1 % of nominal voltage
Range: 0 - 150 % of the nominal voltage
0 % = OFF, the amplitude voltage asymmetry is disabled
Default setting: 20%
V Unb Del
Delay of the voltage unbalance (amplitude asymmetry) protection.
Step: 0,01 s
Range: 0,00 - 600,00 s
Default setting: 5,00 s
V Unb Block BI [ Block 1 / Block 2 / Block 1+2 / None ]
Selection of blocking binary input for voltage asymmetry protection.
