InteliVision 5 - Global Guide
16
3.1.1 LEDand Buttons
Status: Status LED indication (green = InteliVision 5 is powered)
Navigation buttons: Arrows for movement + Menu and Enter button
Context buttons: Control or select submenu/sub-options buttons
Control buttons: Horn reset, Fault reset, Stop and Start buttons
3.1.2 Navigation Buttons
Menu Movement up
Enter Movement down
↓ Jump to menu/sub-menu page or escape from any dialog window
↑ Confirms a value or opens a value adjustment within setting dialogs
Note: To leave the menu, use Menu button.
