l. Open the front door (L) by
prizing on the upper area using
a screwdriver.
m. Record the IP address of
module AMS-IAM available on
the rotating selector switches
(M) to be able to set it in the new
module.
n. If necessary, remove the
interface module:
n.1 Using a screwdriver, push
gently upwards, prizing on the
inside tooth (J) available on the
interface module.
Operating procedure (Continued)
