Components & Controls
27
C3M2-OM-EN-02
Section 3: Components & Controls
All operators must be familiar with the Combilift trucks main components and controls,
their function and where they are located before commencing operation of the truck.
The major components are labelled in figure 3.1 below.
3.1 Machine Overview and Components
Figure 3.1 Machine Components Layout
Components
1. Operator’s Cabin
2. Mast
3. Hydraulic Tank
4. Load Platform
5. Front Right-Hand Swivel Arm
6. Fork
7. Fork Carriage
8. Front Left-Hand Swivel Arm
9. Cabin Access Step
10. Diesel Tank/LPG Bottle
11. Cabin Access Handgrip
12. Windscreen Wiper
13. Work Light
14. Rear Swivel Arm
15. Right-Hand Side Access Panel
16. Battery Isolator Key Switch
17. Bonnet
18. Mirror *
19. Exhaust
20. Flashing Beacon
* If Fitted
1
2
3
7
6
9
8
4
5
10
11
12
13
14
15
16
17
18
19
20
