Operation
83
C3M2-OM-EN-02
5.16.1 Undercutting a Load
This is when the forks are not fully inserted into the pallet or under a load. It may be
necessary to do this when it is not possible to get close enough to the pallet/load to
insert the forks fully.
To Pick Up a Load using Undercut:
Fully extend the reach to insert the forks as far as possible into the pallet or under
the load.
Gradually lift the load just enough to ensure it is stable.
If the load is unstable lower it back to its original position and report the problem
to the site supervisor.
If the load is stable, retract the reach fully to bring the load closer to the truck.
Reverse slowly just enough to clear the racking/stack.
Lower a long load onto the trucks platforms ensuring that it is properly supported
and stable on the platforms.
Lower a palletised load onto the ground.
Extend the reach again until the load is against the front face of the forks.
The load is now ready to be lifted.
Position the load in the safe travel position.
To Set Down a Load using Undercut:
After transporting the pallet/load, extend the reach fully then lower it onto on the
ground.
Reposition the forks the required distance back from the load. The forks must be
inserted by at least two thirds the depth of the pallet/load.
Gradually lift the load just enough to check that it is stable.
If the load is unstable lower it back onto the ground and report the problem to the
relevant supervisor.
If the load is stable proceed to stack it in the usual fashion. See section 5.16.4
‘Stacking Long & Palletised Loads’ on page 85.
Warning
The load centre is increased and therefore the lifting capacity is reduced
when the front face of the forks is not touching the load.
Ensure the truck has sufficient capacity to cope with the increase in load
centre.
