Operation Monitoring
47
C3M2-OM-EN-02
Indicators such as the oil pressure icon or the coolant temperature icon may
light up on the home screen if applicable.
The ECU will store information that will allow the fault to be diagnosed when a
computer is connected to the ECU.
Engine fault codes can be viewed on the ‘Engine Information’ screen. See
section 4.5 ‘MDC Engine Fault Codes’ on page 56 for instructions on how to
view engine fault codes.
9. Side Road Lights Icon **
The side road lights icon can only light up on trucks that have
optional road lights fitted.
The icon will light up green while the side road lights are illuminated.
** Only applies if road lights have been fitted.
10. Headlights Icon **
The headlights icon can only light up on trucks that have optional
road lights fitted.
The headlights icon lights up blue while the headlights are
illuminated.
** Only applies if road lights have been fitted.
11. Low Engine Oil Pressure Warning Icon
When the key switch is turned to position 1 (operating voltage) the
low engine oil pressure warning icon should light up red to confirm
the icon is functioning.
If the low engine oil pressure warning icon is lit up red when the
engine is ‘running’ it indicates low engine oil pressure and/or
insufficient oil in the sump.
Stop the engine and investigate the issue (see section 5.3
‘Checking Engine Oil Level’ on page 66).
12. Battery Charge Warning Icon
When the key switch is turned to position 1 (operating voltage) the
battery charge warning icon should light up red to confirm the icon
is functioning.
If the icon is lit up red when the engine is ‘running’ it indicates that
the alternator is not providing enough voltage to power the electrics
and charge the battery.
13. Park Brake Icon
The park brake icon lights up red when the park brake is applied.
Note
Stop the engine if the low engine oil pressure icon is red when the engine is
running. Check the oil level on the dipstick. Check for oil leaks.
