Operation Instructions
5-7
5) [Report text]: [Off], [basic], [detailed].
When it is set as [Off], there is only information set in the [Register];
When it set as [Basic], the print information include: information set in the [Register], interval,
electrical axis, amplitude, etc;
When it is set as [Detailed], the print information include: information set in the [Register], interval,
electrical axis, amplitude, Minnesota code, diagnosis information, etc;
6) [Average Template]: [3×4+1R], [6×2+1R], [Off].
When it is set as [3×4+1R], 12 leads of average template waveforms are recorded in 3 channels and
4 sequences and add 1 average template waveform of the rhythm lead.
When it is set as [6×2+1R], 12 leads of average template waveforms are recorded in 6 channels and
2 sequences and add 1 average template waveform of the rhythm lead.
When it is set as [Off], there is no average template output.
7) [Save Options]: [save data], [off]
[Save data] means the patient cases are saved in the format of data in the electrocardiograph
When [printer select] is set as [image] and the [save option] is set as [save data], there are two
patient cases saved, one is identified by ID+D, and another is identified by ID+G.
When [printer select] is set as [internal] and the [save option] is set as [save data], there is only
patient data saved, identified by ID+D.
When the save option is set as [off], the ECG data recorded under the automatic working mode will
not be stored in the document management “File” interface.
8) [Printer Select]: [Internal], [External], [Image], [Off].
Select [Internal] to use the built-in heat sensitive array printer;
Select [External] to use an external printer, like PANTUM P3255DN
Select [Image] not to use the internal or external printer, but to save the patient's waveforms and
information as an image file identified by ID+G; When select [Off], there is no print and no save.
The external printer is optional.
Only use the external printer supplied or recommended by us, or it may fail to be recognized by
the ECG machine or cause damage to reduce the performance and safety of the machine
Currently our ECG machine CM1200B supports such external printers as PANTUM P3255DN.
The electrocardiograph supports transform the patient cases identified by ID+D in RECALL
interface to the patient cases identified by ID+G, the method is: set the [printer select] as [image]
in print setting window, return to recall window and select the patient case identified by ID+D to
print. By doing this, the patient case of data format can be transformed to that of image format.
9) [Paper Style]: [rolled 210mm], [rolled 216mm], [folded 140×210mm], [folded 140×216mm]
There are two kinds of record paper supported by this electrocardiograph: rolled thermosensitive record paper
and folded thermosensitive record paper. When no record paper is loaded or the record paper is used up,
[Paper?] will be displayed on the LCD screen to remind the user of loading or replacing the record paper.
