30
6.2 ECG Test
6.2.1 ECG Performance Test
Tool required:
Fluke Medsim 300B, MPS450 or other patient simulator recommended
Follow this procedure to perform the test:
1. Connect the patient simulator with the ECG module using an ECG cable.
2. Set the patient simulator as follows: ECG sinus rhythm, HR=80 bpm with the amplitudes 1mV.
3. Check the ECG waves are displayed correctly without noise and the displayed HR values within
80 ± 1 bpm.
4. Disconnect each of the leads in turn and observe the corresponding lead off alarm message displayed on
the screen.
5. Set that the simulator outputs paced signals and set [PACE] to [ON] on the monitor’s patient manage
interface. Check the pace pulse marks on the monitor screen.
6.2.2 ECG Calibration
Tool required:
Vernier caliper
Follow this procedure to perform a calibration:
1. Select the 1
st
channel ECG waveform area→ [FILTER]→ [DIA].
2. Select [MAIN MENU]→ [MAINTAIN] →PASSWORD “5188” →[ECG Calibrate].
3. Select [ECG Calibrate]. A square wave appears on the screen and the message [CAL, can’t monitor]
is displayed.
4. Compare the amplitude of the square wave with the wave scale. The difference should be within 5%.
5. After completing the calibration, select [STOP ECG CAL].
If necessary, you can print out the square wave and wave scale through the recorder and then measure the
difference.
6.3 RESP Performance Test
Tool required:
Fluke Medsim 300B, MPS450 or other patient simulator recommended
Follow this procedure to perform the test:
