7.14 Removing the ECG board
1 Separating the front and rear housing as described in Chapter 7.2;
2 Removing the power switch board as describe in Chapter 7.9;
3 Remove the function block as describe in Chapter 7.10.1;
4 Remove the side connection board as describe in Chapter 7.10.3;
5 Unscrew the 3PB 3.0×6.0mm screws and then take off the ECG board.
