Comen NC5 - Functional Boards

11
3.2.2 Functional Boards
3.2.2.1 ECG board
This is a single channel ECG board. Receiving ECG signal and process ECG signal, then send to main
board.
Pin ID J6 J5
Description To DC power supply board To side panel connection board
Working voltage 5V 5V
