UAP2 Accessories and Options
The Fiber UAP2 accessories and opons are described in the following secons:
■ Mounng and Power Kits
■ SFP+ Modules
Mounting and Power Kits
Wall and Ceiling mounng brackets are included with the UAP2. For Ceiling mounng, a 24” drop rail is also
needed. In the NAR market, this drop rail can be ordered as part OC-BA50A. In other markets the drop rail
may not be available as a CommScope part number; look for compable third-party opons such as the
Eaton BA50A.
The UAP2 does not include a power cable. Either the Local AC Power Supply or both the Hybrid Splice Kit
and a UAP2 Power cable must also be ordered.
Note: The Wall / Ceiling Mount adds an addional ~45 mm (1.77“) of depth to the UAP2, totaling a
depth of ~142 mm (5.59”). When the Hybrid Fiber Splice Kit is used, the total depth increases to
~171 mm (6.73”).
TABLE 4: Power Kits and Spare / Replacement Mounng Kits
Mounng /Power Kit CommScope PN See
Wall / Ceiling Mount (without drop
rail for Ceiling Mount)
7849969 "Mounng a UAP2 on a Ceiling” on
page 22 / "Mounng a UAP2 on a
Wall” on page 31
UAP2 Hybrid Fiber Splice Kit 7693816-xx "Mounng a UAP2 with a Hybrid
Splice Kit” on page 15
UAP2 Power Cable, 0.5m 7850085-xx
UAP2 Power Cable, 3m 7850084-xx
UAP2 AC Power Supply 7850080-xx "Mounng a UAP2 with an AC/DC
Power Supply Kit” on page 14
SFP+ Modules
Obtain SFP+ Module pairs (one placed in the TEN and paired with another in the Classic CAN) that are
appropriate for this installaon. Two pairs are needed for each UAP 2 with more than 320MHz RF
Bandwidth.
Table 5: Supported SFP+ Modules (page 15) idenes the available SFP+ modules and the maximum range
for each.
TABLE 5:
Supported SFP+ Modules
CommScope PN Descripon Maximum Range
7660511 SFP+, 10GBase-SRR, Mul Mode OM3 300m
OM4 400m
DRAFT: CONFIDENTIAL
Chapter 2: Fiber UAP2
CommScope ERA
®
UAP2 with Fiber Interface Installaon Guide , Release
P/N M0203AB, DRAFT Rev D 15
