Fiber Low Power Carrier Access Point Installation Guide M0201ANC_uc
Page 20 © June 2019 CommScope, Inc.
Plan and Prepare for a Fiber CAP L Installation
Mounting Dimensions for a CAP L Mounted with the CAP L Hybrid Fiber Splice Box Kit
120mm
[4.72"]
188mm
[7.4"]
383.34mm
[15.09"]
512mm
[20.16"]
2X
30mm
[1.18"]
424.53mm
[16.71"]
390.33mm
[15.37"]
24mm
[0.94"]
2X
460.75mm
[18.14"]
116.3mm
[4.58"]
31.5mm
[1.24"]
170.19mm
[6.7"]
36.75mm
[1.45"]
