CommScope Era
™
Fiber Low Power Carrier Access Point Installation Guide M0201ANC_uc
Page 56 © June 2019 CommScope, Inc.
Connect the Cables to the Fiber CAP L
5 Attach the ring end of the wire to the chassis ground stud, as shown in the graphic below.
6 Use the Keps nut removed in Step 4 to secure the ground wire to the chassis-ground stud.
7 Route the free end of the chassis grounding wire to an approved
(per local code or practice) earth ground
source.
Connect the Fiber CAP L to a Passive RF Antenna
The following sections guide you through connecting the CAP M; complete these procedures in the order in
which they are presented.
• "Clean the RF Cable Connectors” on page 57
• "Connect the Passive RF Antenna” on page 59.
