7. Specifications
MF0121ACP_uc.docx Manual for Node AM4 Page 73
Modulation
Scheme
RF Card
UL
Frequency,
MHz
DL
Frequency,
MHz
Max.
Gain,
dB
Uplink Composite Output
Power, dBm
1)
Downlink Composite Output
Power, dBm
1)
CELL 700,
UMTS 700,
LTE 700
AF 727
698 to 716
and
776 to 787
728 to 757
84
30 (GSM, CDMA,
IDEN, LTE)
28 (UMTS)
27 (GSM, CDMA,
IDEN, LTE)
25 (UMTS)
AF 737 94
30 (GSM, CDMA,
IDEN, LTE)
28 (UMTS)
37 (GSM, CDMA,
IDEN, LTE)
35 (UMTS)
CELL 850,
UMTS 850,
LTE 850
AF 8527
824 to 849 869 to 894
84
30 (GSM, CDMA,
IDEN, LTE
28 (UMTS)
27 (GSM, CDMA,
IDEN, LTE)
25 (UMTS)
AF 8537 94
30 (GSM, CDMA,
IDEN, LTE)
28 UMTS
37 (GSM, CDMA,
IDEN, LTE)
35 (UMTS)
CELL 900 AF 9037 896 to 902 935 to 941 94 30 (GSM, CDMA, IDEN) 37 (GSM, CDMA, IDEN)
CDMA 1700
3)
,
UMTS 1700
3)
,
LTE 1700
3)
AF 1727
1710 to 1755 2110 to 2155
84 30 (CDMA, LTE) 28 (UMTS) 27 (CDMA, LTE) 25 (UMTS)
AF 1737 94 30 (CDMA, LTE) 28 (UMTS) 37 (CDMA) 35 (UMTS) 36 (LTE)
LTE 1700
3)
AF1727E 1710 to 1780 2110 to 2180 84 30 (CDMA, LTE) 28 (UMTS) 27 (CDMA, LTE) 25 (UMTS)
GSM 1900
CDMA 1900,
LTE 1900
AF 1927
1850 to 1915 1930 to 1995
84 30 (GSM, CDMA, LTE) 27 (GSM, CDMA, LTE)
AF 1937 94 30 (GSM, CDMA, LTE) 37 (GSM, CDMA, LTE)
LTE 2600
2)
AF 2625
2500 to 2570 2620 to 2690
82 27 25
AF 2635 92 27 35
1)
Output power per carrier (dBm) = composite output power (dBm) - 10
x
log (no. of carriers)
2)
LTE uplink composite output power (dBm) valid for sub-bands ≤ 10 MHz
3)
To fulfill the FCC the UL requirement of 1 Watt EIRP max. for the AWS uplink band, the type of donor antenna
must be selected in a way not to exceed the 1 Watt. EIRP. Antenna type selection and execution of installation
has to be done in accordance to the relevant FCC part and is in responsibility of the installer.
table 7-2 RF card options for USA, single band cards
RF Card
Modulation
Scheme
UL
Frequency,
MHz
DL
Frequency,
MHz
Max. Gain,
dB
Uplink Composite
Output Power, dBm*
Downlink Composite
Output Power, dBm*
AF824/923
(combined
antenna ports)
LTE 800 832 to 862 791 to 821
70
27 25
EGSM 900,
UMTS 900,
LTE 900
880 to 915 925 to 960
24 (GSM)
27 (UMTS, LTE)
22 (GSM)
25 (UMTS, LTE)
AF 1823/2125
(combined
antenna ports)
GSM 1800,
LTE 1800
1710 to 1785 1805 to 1880
72
26 (GSM)
27 (LTE)
23 (GSM)
25 (LTE)
UMTS 2100,
LTE 2100
1920 to 1980 2110 to 2170
27 (UMTS, LTE) 25 (UMTS, LTE)
* Output power per carrier (dBm) = composite output power (dBm) - 10
x
log (no. of carriers)
table 7-3 RF card options, dual band cards
