Page #79 background imageLoading...
Page #79 background image
8. Spare Parts List
MF0121ACP_uc.docx Manual for Node AM4 Page 79
8. Spare Parts List
The following list contains all FRUs available for the Node AM4. The Node AM4
configuration is available in the web interface.
Designation ID No
Node AM4 7613589
A
dapter Kit Modem Node AM
1)
7817687
Combiner Kit 8-9/18/21 GPS, VSWR 7617865
Combiner Kit 8/9/18/21 GPS, VSWR
1)
7635384
Combiner Kit 8/9/18-21/26 GPS, VSWR
1)
7697443
Combiner Kit 8-9/18/21/26 GPS, VSWR
1)
7697689
Combiner Kit 7/8-9/18-21/26 GPS, VSWR
1)
7703442
Combiner Kit 7/85/17E/19 7817692
Cover
(
for transport protection
)
7703683-00
DCM
Com-
mercial
Applica-
tions
(EMEA)
DCM AF 7524
(
703-748 / 758-803 MHz
)
7761303-00
DCM AF 7524L
(
703-733 / 758-788 MHz
)
7761306-00
DCM AF 824
(
832
862 / 791
821 MHz
)
2)
7661357-01
DCM AF 824
(
832
862 / 791
821 MHz
)
7621773-01
DCM AF 824/923 combined ports
(
832 to 862/791 to 821 MHz & 880 to 915/925 to 960 MHz
)
7693191-00
DCM AF 835
(
832
862 / 791
821 MHz
)
7621771-01
DCM AF 923 R
(
876 - 880 / 921 - 925 MHz
)
7606744-01
DCM AF 936 R (876 - 880 / 921 - 925 MHz) 7606746-01
DCM AF 923 RE
2)
(876 to 915/921 to 960 MHz)
(
requires Slot Duplexer 7621867-00
)
7621746-01
DCM AF 936 RE (876 to 915/921 to 960 MHz)
(requires Slot Duplexer 7621867-00)
7625530-01
DCM AF 923 (880 - 915 / 925 - 960 MHz) 7562492-01
DCM AF 923
(
880 - 915 / 925 - 960 MHz
)
2)
7630563-01
DCM AF 936
(
880 - 915 / 925 - 960 MHz
)
7562493-01
DCM AF 1823
(
1710 - 1725 / 1805 - 1880 MHz
)
7562494-01
DCM AF 1823
(
1710 - 1725 / 1805 - 1880 MHz
)
2)
7630565-01
DCM AF 1823/2125 combined ports
(
1710 to 1785/1805 to 1880 MHz
)
7700741-00
DCM AF 1835
(
1710 - 1725 / 1805 - 1880 MHz
)
7562495-01
DCM AF 2125
(
1920 - 1980 / 2110 - 2170 MHz
)
7562496-01
DCM AF 2125
(
1920 - 1980 / 2110 - 2170 MHz
)
2)
7626358-01
DCM AF 2135
(
1920 - 1980 / 2110 - 2170 MHz
)
7562497-01
DCM AF 2625 (2500 - 2570 / 2620 - 2690 MHz) 7621749-01
DCM AF 2635 (2500 - 2570 / 2620 - 2690 MHz) 7621747-01
1)
To avoid a collision between modem connectors and combiner, the adapter kit 7817687 for modem
installation (see figure 5-1) is used. If it is not yet installed, order it together with the new combiner.
2)
Railway approved cables
