8. Spare Parts List
Page 80 MF0121ACP_uc.docx Manual for Node AM4
Designation ID No
Node AM4 7613589
DCM
Com-
mercial
Applica-
tions
(US)
DCM AF 727 (698 to 716 & 776 to 787 / 728 to 757 MHz) 7577532-01
DCM AF 737 (698 to 716 & 776 to 787 / 728 to 757 MHz) 7598983-01
DCM AF 8527 (824 - 849 / 869 - 894 MHz) 7577540-01
DCM AF 8537 (824 - 849 / 869 - 894 MHz) 7577542-01
DCM AF 1727 (1710 - 1755 / 2110 - 2155 MHz) 7577548-01
DCM AF 1727E (1710 to 1780 / 2110 to 2180 MHz) 7817693-00
DCM AF 1737
(
1710 - 1755 / 2110 - 2155 MHz
)
7577550-01
DCM AF 1927
(
1850 - 1915 / 1930 - 1995 MHz
)
7577552-01
DCM AF 1937
(
1850 - 1915 / 1930 - 1995 MHz
)
7577554-01
DCM AF 9037
(
UL 896 - 902 MHz / DL 935 - 941 MHz
)
7577546-01
DCM AF 8524 (AUS) 7801322-00
Dummy card 7574285-00
Dummy card T5 7643315-00
Fan Unit Backside Type (Kit) 7574286
Fain Unit Bottom 7644217-00
GPS Bias-T cable (AC/DC Cable USB 0.4 M Molex. 3 pol) 7626927-00
Modem-Kit PHS8 Node AM
3)
7679538
Modem-Kit PLS-8 Node AM EU 7724196-00
Power Supply Unit DC IN 24-110 V 680 W 7609268-00
Power Suppl
y
Unit DC IN 24-110V 780W 7711908-xx
Power Supply Unit AC IN 100-240 V 680 W 7605769-00
Rechargeable battery pack 6 V 7613775-00
Slot Duplexer passive (876-915/921-960 MHz) 7621867-00
User Interface 2 - Kit > V2.0.6
4)
7814162
User's Manuals for Node AM4 7617868-00
VSWR Kit 925-960 MHz 7622883
VSWR-Module 925-960 MHz 7614218-00
3)
Modem-Kit PHS8 is the successor of Modem-Kit HC25 which has been discontinued
4)
Due to a PCB update on the UI2 Board (see also chapter 4.3.6), SW version V2.0.6 is mandatory for
this kit (containing UI2 Board 7613646-05). The former User Interface 2 – Kit 7622884 (containing UI2
Board 7613646-03) is no longer available. The UI2 Board cannot be ordered separately
The manufacturer reserves the right to replace the parts listed above by equivalent
substitutes.
 Note: To ensure compatibility with your system, do not order any individual
components (e.g. modems) of the kits available. Make sure to always order
the complete kit (ID must be listed above) as spare part.
