ComNav G3 - Magnetic Heading or True Heading; Figure 18 - G3 Menu Tree

ComNav G3 GPS Compass Installation & Operation
Document PN 29010092 V2.3 - 19 -
Main Menu Descriptions & options
|
--- Settings …
| Backlight
Backlight Level of 1, 2, 3, 4
| Display
Display mode in Blue, Green,
Black, Night
| Units … ---
| Date Format
|
Date format from yymmdd,
mmddyy, ddmmyy
| Time Format
|
Time displays in 12-hour or 24-
hour system
| Heading
|
Heading shown in Auto,
Magnetic or True
| Magnetic Variation
|
Magnetic variation, manually
entered
|
--
- Speed
Speed unit in kn, km/h, mph
| Temperature
Temperature unit in °C, °F
| Depth
Depth unit in m, ft, ftm
| Distance
Distance unit in m, nm, km, mi
| Wind speed
Wind speed in kn, m/s
| volume
Volume unit in l (litre), gal_b
(gallon, UK), gal (gallon, US)
| Flow pressure
Flow pressure in psi, kPa
| Atmosphere Pressure
Pressure in mmHg, inHg, kep
| Flow rate
Flow rate in l/hr (litre per hour,
gal/hr (gallon per hour, US),
gal_b/hr (gallon per hour, UK)
--- Configure …
| Customise …
change the data fields on
screens
| Rescan Data Bus … rescan the bus for transducers
| Assign Devices … select a transducer for a PGN
| Factory default … clear all customer settings
|
--- Advance …
Change PGN rates
…
Setup Devices …
Figure 18 – G3 Menu tree
Magnetic Heading or True Heading
