2
Packet Buffer
1Mbits
MAC Address
8K MAC address table
Flash ROM
4Mbytes
DRAM
32Mbytes
Connector
10/100TX: 8 x RJ45
10/100/1000T/ Mini-GBIC Combo: 2 x RJ45 + 2 x 100/1000
SFP sockets
RS-232 connector: RJ45 type
Network Cable
10Base-T: 2-pair UTP/STP Cat. 3, 4, 5/ 5E cable
EIA/TIA-568 100-ohm (100m)
100Base-TX: 2-pair UTP/STP Cat. 5/ 5E cable
EIA/TIA-568 100-ohm (100m)
1000Base-TX: 2-pair UTP/STP Cat. 5/ 5E cable
EIA/TIA-568 100-ohm (100m)
Optical Fiber
Distance:
Multi mode:
0 to 5 km, 1300 nm (50/125 µm, 800 MHz*km)
0 to 4 km, 1300 nm (62.5/125 µm, 500 MHz*km)
Single mode:
0 to 40 km, 1310 nm (9/125 µm, 3.5 PS/(nm*km))
0 to 80 km, 1550 nm (9/125 µm, 19 PS/(nm*km))
Min. TX Output:
Multi mode: -20 dBm
Single mode: 0 to 40 km, -5 dBm; 0 to 80 km, -5 dBm
Max. TX Output:
Multi mode: -14 dBm
Single mode: 0 to 40 km, 0 dBm; 0 to 80 km, 0 dBm
