Compac C5000 User Manual

36.
LED Diagnostics
K-Factor Board Output LEDs
The following table describes what each output LED represents for each mode. The output LED
will light up when the corresponding outlet is engaged. Outputs for both side A and B are shown.
Mode
T1
T2
T3
T4
T5
T6
T7
Single
Motor A
Primary
Solenoid A
Secondary
Solenoid A
High Flow
A
High
Flow A
Dual
Motor A
Primary
Solenoid A
Secondary
Solenoid A
Motor B
Primary
Solenoid B
Secondary
Solenoid B
High
Flow A
Dual
160
Motor A
Primary
Solenoid A
Secondary
Solenoid A
High Flow
B
Primary
Solenoid B
Secondary
Solenoid B
High
Flow A
Dual
HLB
Motor A
Primary
Solenoid A
Secondary
Solenoid A
Motor B
Primary
Solenoid B
Secondary
Solenoid B
High
Flow B
