Compac C5000 User Manual

17.
K-Factor Settings
Changing Configuration Settings
The dispenser has settings for each side (as previously shown) as well as configuration settings
for the entire unit.
Use the following diagram to set the unit up as desired.
Hardware Variant
The hardware variant refers to the type of dispenser and should always be set to 0 – Dispenser
for dispenser application.
Card Totals
Card totals record the delivery totals for given cards. This is enabled by default but can be
disabled if desired.
Pump Mode
The dispenser can be switched between retail or commercial, depending on the application.
0000002
Pump Settings
1 – Single
2 – Dual
4 – Dual 160
5 – Dual HSB
Hardware Variant
0 – Dispenser
1 – Hybrid
Pump Mode
0 – Retail
1 – Commercial
Card Totals
0 – Enabled
1 – Disabled
