41
.
End of Sale Indicators
End of Sale Indic
ators
The reason for the end of sale
fo
r each transaction is recorded by the unit.
These are helpful for troubleshoo
ting the unit.
Keypad Display
Dispenser Display
Meaning
NOZ
1
Nozzle hung up
PRESET
2
Reached preset
DISP
3
Normal end of delivery
OFFLINE
4
Pump
–
Controller comms disconne
cted
MAX
5
Maximum litres and/or dollars reached
AIR
6
Air switch cut out
ERROR
7
Encoder error
SUMP
9
Sump switch cut out
T
O
ATH
12
Auth timeout
POR
13
Fill ended due to repower or reset
STP SW
14
Stop switch triggered
PRST ERR
15
Invalid preset value entered
DIS OFF
17
K-factor offline or unpaired
DIS PAIR
18
K-factor offline or unpaired
FMS TEM
30
Controller initiated stop
DENSITY
35
Density out of range
TEMP
36
Temperature out of range
MTR ERR
41
Meter error
EXC FLO
43
Meter excess flow
UNKNOWN
0
45
47
Table of Contents
Default Chapter
5
Table of Contents
5
Safety
6
C5000 Power Supply
7
Cable Requirements
8
Incoming Mains
9
Comms Connections
10
Power Supply
11
K-Factor Board
12
Typical Wiring
13
Pumps
13
Dispensers
15
K-Factor Settings
16
Using the Dispenser Menus
16
Dispenser Settings
17
Changing the V50 Meter ID
19
Changing the Temperature Calibration
20
Changing the Density Calibration
20
Changing the Maximum Flow
21
Changing the K-Factor
21
Changing Configuration Settings
22
Changing the Solenoid Delay
25
Changing the Preset Cutoff
25
Changing the Preset Rounding
26
Changing the Flow Time out
27
Parameter Settings
28
Using the Dispenser Menus
28
How to View the Software Version
29
Changing the Pump Number
29
Changing the Price
30
Changing the Pump Settings
30
Changing the Low-Flow Cutoff
32
Changing the High-Flow Cutoff
32
Changing the B Setting
33
Changing the Slave Display Configuration
33
Changing the Custom Display Configuration
34
How to View Last Sale
35
How to View Electronic Totes
36
Commissioning
37
Electrical
37
Mechanical
38
LED Diagnostics
39
Processor Board
39
K-Factor Board
40
Troubleshooting
42
Electrical
42
Mechanical
44
Generator Power
45
End of Sale Indicators
46
Error Codes
47
