Refer to Health and Safety section before carrying
out any service work.
Changing air filter
•
Refer to 1C.
•
Fit parts contained in service kits.
Removing filter support
•
Renew seal (2).
•
Cleandust from filter (4) using low pressure,clean dryair.Renew
filter if necessary.
•
Renew seals (6) and (8).
•
Release vent down pipe from elbow (14).
•
Place drip tray underneath to collect oil spillage.
•
Screw a suitable M 12 bolt into the hole provided in the filter
support (9) to extract it from the intake end cover.
•
Clean filter support and intake end cover.
•
Renew ‘O’ ring (10).
•
If removalof the intakeend cover cap (12) is necessary, ensure a
new gasket (13) is fitted on assembly.
•
On assembly, the filter support (9) should be inserted evenly into
the intake end cover by tightening the support bolt. Ensure that
the servo access hole in the support aligns centrally with the
servo adjusting screw prior to inserting the support. This will
enable easy future adjustment of the servo valve.
Page 22
CompAir Hydrovane
2A Air Intake Arrangement
Item Part Number Description Kit
Quantity
All 705 707
1 MN1708 M8 Philidas Locknut 1
2 57738 Fibre washer KM71 1
3 57737 Filter cover 1
4 50273 Air filter KM71 1
5 57735 Filter support bolt 1
5A 73421 M8 x 40 stud 1
6 57739 Fibre washer KM71 1
7 58183 Servo valve access plug 1
8 9619 Bonded seal 3/4 1
9 71141 Filter support 1
10 9842 ‘O’ Ring KM71 1
11 MS706-25 Socket head screw M6 x 25 3
12 73626 Bearing end cap 1
13 58024 Gasket KM71 1
14 73283 Male stud elbow ¼ BSPT - 6mm 1
15 MS2105-16 Pan head screw M5 x 16 2
16 71140 Intake baffle 1
17 MW5 Washer M5 2
18 MN1705 Nut 2
