CompAir Classic 05 - Intake End Cover - Removal

Refer to Health and Safety section before carrying
out any service work.
Intake end cover removal
•
Standdriveendof compressor oil chamber on a raisedplatform.
•
Unscrew and remove stator nuts (1).
•
Insert rounded tyre levers between the intake end cover flange
and the oil chamber.Carefully lever the intake end cover clear of
oil chamber.Position levers opposite each other to achieve even
leverage. Avoid damage to end cover O ring groove.
•
Inspectinner face of intakeend coverandits white metal bearing
for damage, wear or score marks. Renew complete intake end
cover assembly if any damage is found.
•
Fit parts contained in service kit.
Page 48
CompAir Hydrovane
2K Intake End Cover - Removal
Item Part Number Description Kit
Quantity
All 705 707
1 57747 Stator nut M12 14
2 9609 Bonded seal 1/4 KT71 14
