Refer to Health and Safety section before carrying
out any service work.
Note: Drain compressor oil prior to servicing the following item.
Refill with oil after service completion.
Oil Filter
•
Wash the filter element (21) in white spirit or paraffin and blow
dry. Clean out the oil filter bore.
•
Ensure that the filter is fitted with the centre boss (arrowed)
facing outwards.
•
Renew ‘O’ ring (20).
Page 38
CompAir Hydrovane
2F Oil Chamber Arrangement
Item Part Number Description Kit
Quantity
All 705 707
21 0941/1 Oil filter 1
23 9619 Bonded seal KT71 2
24 0066 Filler plug 1
25 9613 Bonded seal KM71 1
26a 74061 Thermistor probe - std 1 1
26b 71812 Thermistor probe - electronic 1
28 50350 Eye bolt 1
29 59425-03 Plug 1
30 74003 Temperature probe - electronic 1
