Refer to Health and Safety section before carrying
out any service work.
Replacing separator element
•
Remove the eight retaining screws (1) securing the separator
cap to the oil chamber.
•
Lift assembly out of oil chamber and place on workbench.
•
Unscrew separator element.
•
Clean all components.
•
Fit parts contained in service kit.
Note: If separator studs (10) have been removed, screw into cap
first not into elements.
Page 54
CompAir Hydrovane
2M Oil Separator Assembly
Item Part Number Description Kit
Quantity
All 705 707
1 MS706-20 Socket head screw 8
2 MWG6 Spring washer 8
34400 Separator cap assembly 1
3 74012 Cap
4 59425-03 Taper plug brass 3/8” BSP 1
5a 74158 Nameplate - Classic 1
5b 71163 Nameplate 1
6 56391 Pressure gauge KT71 1
7 MS2105-10 Pan head screw M5x10 2
8 refer to Ventdown assemblies
9 MS703-10 Cap head screw M3x10 2
10 58341 Separator stud M8 1
11 59177 Separator element 1
12 9799 O Ring 1
13 57803 Gasket 1
