CompAir Classic 05 - Rotor Stator Unit - Dismantling

Refer to Health and Safety section before carrying
out any service work.
Rotor Stator Unit - Dismantling
•
Drain compressor oil.
•
Remove compressor from motor.
•
Remove bell housing.
•
Remove compressor coupling and oil seal housing.
•
Remove air intake filter arrangement.
•
Remove valves from intake end cover.
1. Intake End Cover Removal
•
Stand drive end of compressor oil chamber on wooden blocks.
•
Unscrew and remove seven stator nuts (5) and discard bonded
seals (6).
•
Use the gap between the intake end cover flange and the oil
chamber to lever the intake end cover clear of the oil chamber.
Use two levers positioned diagonally opposite each other to
achieve evenleverage and ease extraction.Avoid damage to the
end cover ‘O’ ring groove.
•
Discard ‘O’ ring (7).
Inspect inner faceof intake end coverand its white metal bearing (3)
fordamage, wear or score marks.Renew intake end cover complete
if any damage is found.
Page 30
CompAir Hydrovane
2E Rotor Stator Unit - Dismantling
Item Part Number Description Kit
Quantity
All 705 707
7
Bar
10
Bar
7
Bar
10
Bar
1a 32549 Intake end cover assembly 1 1
1b 32748 Intake end cover assembly 1
2 59425-01 Taper plug brass 1/8 BSP 2
3 0782 Bearing 1
4 MG1706-6 Grub-screw tuflock M6 x 6 3
5 57747 Stator nut M12 14
6 9609 Bonded seal 1/4 14
7 9900 O Ring KT71 1
8a 58017-02 Gasket 0.04mm A/R 1 1 1
8b 58017-03 Gasket 0.05mm A/R KT71 1 1 1
8c 58017-04 Gasket 0.08mm A/R KT71 1 1 1
8d 59370-03 Gasket 0.05mm A/R KT71 1
8e 59370-04 Gasket 0.08mm A/R KT71 1
9 57746 Stator stud M12 7
10 58410 Deflector 1
11 MS105-12 Hex head screw M5 x 12 2
12 MWG5 Spring washer M5 2
