Page 60
CompAir Hydrovane
2Q Dryer
Item Part Number Description Kit
Quantity
All 705 707
1 1068 Tubing nut 1*
2 1069 Tubing sleeve 1*
3 1911 Stud elbow c/w nuts 2
4 34447 By-pass kit comprising:- 1
5 72956 Stud elbow ½ -20mm 3
6 74150 Ball valve 3-way 2
7 74151 Pipe, dryer to by-pass 2
8 74152 Stud coupling 2
9 74153 Elbow, equal 2
10 74154 Sleeve 1
11 3679 Drain filter 1
12 50463 Straight stem adapter 1*
13 53682 Elbow, 8 mm standpipe 1*
14 58076 Grommet 1*
15 58077 Filter 1*
16 70661 Solenoid valve 1*
17 73961 Base 1
18a 74108 Refrigerant HBD 56 (05) 1
18b 74140 Refrigerant HBD 76 (07) 1
19 74155 Pipe, filter to by-pass 1
20 74156 Stem adaptor 1
21 74157 Cable assy, solenoid valve 1*
22 MS108-20 Screw, hexagon head M8 x 20 4
23 MS110-20 Screw, hexagon head M10 x 20 6
24 MWG 10 Washer, spring M10 6
25 MWG 8 Washer, spring M8 4
* Denotes only used with Electronic Control.
