CompAir Classic 05 - Assembling the Rotor Stator Unit - Continued

Refer to Health and Safety section before carrying
out any service work.
Assembling the rotor stator unit - continued
•
Using a straight edge and feeler gauges, check the end
clearance between the rotor and stator.
•
The correct clearance between the rotor face and stator face is
0.2 mm. This clearance must be maintained to ensure correct
compressor operation and performance.
•
Apply a smear of approved oil to the end of the stator and fit the
required size shim/s (7) to give the correct total end clearance of
0.2 mm.
•
After applying oil to its bearing, refit the intake end cover (1) to
thestatorensuring a new‘O’ring (6) is fitted.Intake end cover will
fit over the studs in only one position.
•
Refit stator nuts ensuring new bonded seals are used.
•
Refit new oil seal housing and refit compressor coupling.
•
Refit bell housing
•
Refit valves to intake end cover.
•
Refit air intake arrangement.
•
Refit compressor to motor.
•
Refill compressor with an APPROVED OIL and carryout the test
procedures.
Page 52
CompAir Hydrovane
2L Assembling the Rotor Stator Unit ... Continued
Item Part Number Description Kit
Quantity
All 705 707
33831-01 Intake end cover assembly 1 1
33831-02 Intake end cover assembly
1 58039 Intake end cover 1 1
2 59425-04 Taper plug brass 1/2 BSP (non-servo) 2 2
3 MG1706-6 Grub screw tuflock M6 x 6 1
4 MG1706-6 Grub screw tuflock M6 x 6 (servo) 2 2
5a 59425-01 Taper plug brass 1/2 BSP (servo) 2 2
0782 Bearing (refer to chapter 3H) 1
6 9900 O Ring KT71 1
7a 58017-02 Shim 0.04 mm
7b 58017-03 Shim 0.05 mm
7c 58017-04 Shim 0.08 mm
7d 59370-03 Shim 0.05 mm A/R A/R
7e 59370-04 Shim 0.08 mm A/R A/R
8 9609 Bonded seal 1/4 KT71 14
9 57747 Stator nut M12 14
A/R = As required
