Refer to Health and Safety section before carrying
out any service work.
Service schedules
•
Clean all components.
•
Fit parts contained in service kits.
•
Check freedom of piston (8) in body before assembly.
•
Refer to chapter 6 for M.P.V setting procedure.
Page 56
CompAir Hydrovane
2N Minimum Pressure Valve Assembly
Item Part Number Description Kit
Quantity
All 705 707
1 MCI-30 Circlip internal 1
33413 Minimum pressure valve assembly
2 73283 Elbow 1
3 58470 Adjuster plug 1
4 57742 M.P.V. Body 1
5 9758 O Ring KM71 1
6 9717 O Ring KM71 1
7 9711 O Ring KM71 1
8 57842 M.P.V. Piston 1
9 57588 Spring 1
10 57845 M.P.V return spring 1
11 71760 Non return valve 1
12 0071 M.P.V. Seat KM71 1
13 W3 Washer 3/16 1
14 MCE4-8 Circlip external 1
15 34238 Nylon tube 1
