Page 64
CompAir Hydrovane
2S Ventdown Assemblies
Item Part Number Description Kit
Quantity
All 705 707
D.O.L STANDARD CONTROL
1 73220 Solenoid valve 110 V N.O. 1
2 73215 Elbow, push-in, R 1/8 “ -6mm 3
3 73283 Elbow, push-in, R 1/4 “ -6mm 2
4 73282 Tee, push-in, 6 mm 1
5 ST214671 Tube, nylon, 6 mm A/R
6 74139 Equal nipple R 1/8 ” 1
STANDARD / ELECTRONIC CONTROL
1 73220 Solenoid Valve 110 V N.O. 1
2 74057 Solenoid Valve 110 V N.C. 1
3 74059 Standpipe adaptor R 1/8 “ -6mm 2
4 73449 Stud, push-in,, male, R 1/8 “ -6mm 2
5 73282 Tee, push-in, 6 mm 3
6 73283 Elbow, push-in, R 1/4 “ -6mm 2
7 73215 Elbow, push-in, R 1/8 “ -6mm 3
8 ST214671 Tube, nylon, 6 mm A/R
9 74060 Solenoid valve bracket 1
