CompAir Classic 05 - Bell Housing

Refer to Health and Safety section before carrying
out any service work.
Compressor removal / re-fitting
•
Disconnect the thermistor / thermoswitch probe cable from
either the pressure switch assembly (PURS) or the starter
assembly (PUTS).
•
Drain the oil from the compressor and cooler into a suitable
container.
•
Disconnect the pipework from the compressor to aftercooler,
where applicable.
•
Support the compressor beforeremoving4 off nuts and washers
from the motor flange.
•
If required remove 4 off cap head screw securing the backplate,
where fitted.
•
Remove the compressor from the support and place on a
suitable work surface.
Removing bell housing
Using an extension socket remove screws and washers.
Page 44
CompAir Hydrovane
2H Bell Housing
Item Part Number Description Kit
Quantity
All 705 707
1a 71111 Bell housing 1
1b 71987 Bell Housing
2 RO10000-331 Grommet 1
3a MST12-60B Stud M12 2
3b UFST8-16B Stud ½” x2”
4 MW12 Washer M12 4
5 MWG12 Spring washer M12 4
6a MN112 Nut M12 4
6b UFN 108 Nut ½” UNF
7 57039 Stud M12 2
8 MS712-35 Socket head screw M12 x 35 3
9 MWG12 Spring washer M12 3
10 73326 Stud coupling 1.2” - 15mm 2
