CompAir Classic 05 - Assembling the Rotor Stator Unit

Refer to Health and Safety section before carrying
out any service work.
Assembling the rotor stator unit
•
Check discharge pipe in oil chamber for condition and tightness.
If replacement or tightening of the pipe is necessary, separator
cap must be removed to obtain access to the pipe locknut. Pipe
mustbe positioned parallelwiththe end faceof the oil chamber
•
If stator studs (1) have been removed, apply loctite and screw
fully into the oil chamber.
•
Clean all components.
•
Fit parts contained in service kits.
•
Refitthe stator nuts (3) ensuring newbonded seals (2) areused.
•
Refit rotor (11), complete with blades (12) into oil chamber.Take
carenot to damage bearing in oil chamber when insertingrotor.
•
Refit cowl (7) to flange on intake end of stator (wider flange).
Cowl must be fitted in exactly the same position as that prior to
dismantling.
•
Apply a smear of oil to shim (9) and affix to the drive end face of
the oil chamber. Take care not to damage shim when fitting over
studs (1).
•
Locate stator (10) over studs (1).With jubilee clip to the top lower
it fully into the oil chamber.
Note: Stator can only be fitted one way due to the position of the
stator studs and holes.
Page 50
CompAir Hydrovane
2L Assembling the Rotor Stator Unit
Item Part Number Description Kit
Quantity
All 705 707
1 57746 Stator stud M12 7
2 9609 Bonded seal 14
3 57747 Nut M12 14
4a 58017-02 Shim 0.04 mm
4b 58017-03 Shim 0.05 mm KT71
4c 58017-04 Shim 0.08 mm KT71
4d 59370-03 Shim 0.05 mm KT71 A/R A/R
4e 59370-04 Shim 0.08 mm KT71 A/R A/R
5 MS105-12 Screw M5 x 12 1
6 MWG5 Spring washer M5 1
7 58411 Impingement cowl 1
8 58691 Jubilee clip KT71 1
9a 58018-02 Shim 0.04 mm KT71
9b 58018-03 Shim 0.05 mm KT71
9c 58018-04 Shim 0.08 mm KT71
9d 59302-03 Shim 0.05 mm A/R A/R
9e 59302-04 Shim 0.08 mm A/R A/R
10 Stator assembly
11a 58186 Rotor (10 bar)
12a 59186-02 Blade (10 bar)
12b 59187-02 Blade (10 bar) 12
12c 72364-01 Blade (10 bar) 12
A/R = As required
